The copper crimp makes a secure connection, while the silicone filled housing protects splices from harsh outdoor elements. Designed and manufactured in the USA, you can trust Dry-Crimp connectors for quality, long lasting splices.
Dri-Splice Connector DS-400 (Dry-Crimp)
$2.39
Description
Dry-Crimp Filled Connector
DryConn Dry-Crimp Filled Connector: DryConn Dry-Crimp wire connectors are crimp-style wire connectors perfect for use in low voltage lighting applications. The copper crimp makes a secure connection, while the silicone filled housing protects splices from harsh outdoor elements. Designed and manufactured in the USA, you can trust Dry-Crimp connectors for quality, long lasting splices.
- Copper crimp with protective housing
- Two crimp sizes available to cover a wire range from #18 – #10 AWG
- Manufacturer approved for direct bury
- Allows installer to test connection prior to waterproofing splice
- For use in irrigation systems and low voltage lighting applications
- Max. Voltage: 50V
- Wire Type: Copper
- Wire Range: Min #18/Max #10
Additional information
| Weight | 0.03 lbs |
|---|
Installation
IMPORTANT: Turn off power before installing or removing connector.
Product to be used in accordance with local and national codes.
1. Insert wires through holes in base of body.
2. Twist stripped wires together and apply crimp sleeve with an indent type crimping tool. Trim excess bare wire.
3. DS-100 ONLY — Fill Plug to brim with DS-300 sealant.
4. Invert body and insert plug into body until it snaps tight.
5. Push wires all the way into the plug to completely seal the crimp sleeve.
6. DS-100 ONLY — Be certain sealant has formed into all holes in body.
Specifications
• Connector Size: 21/32” x 5/16”
• Maximum Voltage: 600V max. building wire (1000V max. signs or luminaries)
• Silicone Sealant: -45°F to 400°F
• Temperature Rating: 105°C (221°F)
• Wire Range: Min #22/Max #12
• Wire Type: Copper/Copper
Features
• All the features of the DS-100, plus the added benefit of being pre-filled with Dielectric Silicone Sealant
• Reduced inventory requirements
• Insures proper amount and type of Sealant every time
• Eliminates costly waste and clean-up
