Hunter I-40-04-SS-ON, 4″ Stainless Steel Riser, Pop-up Sprinkler

The Hunter I-40-04-SS-ON is a tough commercial rotor that delivers water with accuracy and efficiency at distances up to 70 feet. It features a diverse three-port nozzle option A non-strippable drive, and a thick rubber cover are featured to prevent injury. No wonder this rotor is found in more stadiums than any other in the world.

With the strength of stainless steel, this stainless steel pop-up sprinkler is built to last in the harshest sports, public park, and commercial environments. Efficiency, effective irrigation, and beautiful results are the goal of any irrigation professional, so the I-40-04-SS-ON is their best solution.

• 4″ Pop-up
• Full circle opposing nozzles
• Reclaimed water ID
• #23 nozzle

• Athletic fields
• Commercial/Municipalities
• High vandalism areas
• Reclaimed water

• Arc setting: 50 to 360 degrees
• Factory installed rubber cover
• Models stainless riser: 4″, 6″
• Nozzle choices: 12
• Nozzle ranges I-40: #8 to #25
• Nozzle ranges I-40-ON: #15 to #28
• Quick check arc mechanism
• Through-the-top arc adjustment
• Water lubricated gear-drive
Automatic Arc Return
Drain Check Valve (up to 10 ft. of elevation)
Non-Strippable Drive
Opposing Nozzle 360˚ Model
Optional Reclaimed Water ID
Part- and Full-Circle in One Model
Color Coded Nozzles
Stainless Steel Riser

• Flow rate I-40: 7.6 to 29.5 GPM
• Flow rate I-40-ON: 13.0 to 33.7 GPM Nozzle trajectory: 25 degrees
• Operating pressure range: 40 to 100 PSI
• Precipitation rates: 0.4 in/hr approx.
• Radius I-40: 44′ to 69′
• Radius I-40-ON: 52′ to 76′
• Recommended pressure range: 40 to 100 PS
• Exposed Diameter: 2″
• Inlet Size: 1″ female NPT
• Overall Height: 7-7/8″
• Pop-up Height: 4″

Brochure
Details

Warranty period: 5 years
