FX Luminaire DE LED Down Light, for the Appearance of Natural Light

The FX Luminaire DE LED Down Light down light was built to help designers create the appearance of natural light in complicated areas. It has an array of water protection features to ensure long life. The DE can handle up to a 9LED and is available in all powder coat colors and as a wall mount. It is also available with ZD Technology® to be compatible with the Luxor ZD Zoning and Dimming Controller. The DE includes your choice of LED board, choice of finish, 23 ft. cable.

Please Allow 12-16 business days for shipping
No returns on lighting products

Additional information

Weight 2.2 lbs
Finish Options

, , , , , , ,


, , ,

Zoning & Dimming Option


Mount Option



DE Included

DE: Includes fixture, specified LED board, filters, and choice of finish

Included Filters




Finish Chart
Powdercoat Finish Options


White Gloss


Flat White




Bronze Metallic


Desert Granite


Weathered Iron


Verde Speckle


Sedona Brown


Flat Black

DE Ordering Information

Factory Installed Options: Order 1 + 2 (optional) + 3 + 4 (optional) + 5

Step Description Code
1 Fixture Code DE
2 Optional ZD ZD (zoning and dimming capability using ZD Technology™ with the Luxor controller)
3 Lamp 1LED (50,000 avg. life hours)
3LED (50,000 avg. life hours)
6LED (50,000 avg. life hours)
9LED (50,000 avg. life hours)
4 Optional Mount WM (Wall Mount)
5 Finish XX (See finish chart)

Example: DE-ZD-9LED-WM-DG = DE – ZD Option – 9LED Board – Wall Mount – Desert Granite Finish


DE Specification Chart

Number of LEDs 1 3 6 9
Halogen Lumen
Output Equivalent
10 Watt 20 Watt 40 Watt 50 Watt
Useful LED Life (L70) 50,000 hrs avg 50,000 hrs avg 50,000 hrs avg 50,000 hrs avg
Input Voltage 10 to 15V 10 to 15V 10 to 15V 10 to 15V
VA Total
(Use this number to
size the lighting controller)
2.4 4.5 13.5 13.5
Watts Used 2.0 4.2 10.1 11.2
Lumens per Watt
29.3 41.1 31.2 27.9
Max Lumens 59 162 328 334
CRI (Ra) 81.2 79.2 79.4 80.2

DE Photometrics

Beam angle is calculated using LM-79 method for SSL Luminaires: “Beam angle is defined as two times the vertical angle at which the intensity is 50% of the maximum.”

DE Dimensions
