$76.73 – $110.98
Available on backorder
The FX Luminaire LF LED Wall Light can easily be fitted between a block wall and capstone for a neat, clean installation. Due to its modular bracket design, the LF can even be installed under railings and existing construction. This light includes a 1LED board,choice of faceplate finish, and a 9 ft lead wire.
Please Allow 12-16 business days for shipping
No returns on lighting products
| Weight | 0.94 lbs |
|---|---|
| Finish Options | BS-Brass, CU-Copper, DG-Desert Granite, No Faceplate, SB-Sedona Brown, Stainless Steel |
| Zoning & Dimming Option | |
| Color Temp | W-Warm 2700K, C-Cool 3900K |
| LF: Includes fixture, 1LED board, filters, and choice of faceplate finish | ||||||||
|---|---|---|---|---|---|---|---|---|
 LF |
Included Filters | |||||||
 Amber |
||||||||
 Frosted |
||||||||
| Metal Finish Options | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
 |
 |
 |
||||||
ABAntique Bronze* (On Brass) |
ABAntique Bronze* (On Copper) |
ATAntique Tumbled* (On Brass) |
ATAntique Tumbled* (On Copper) |
CUCopper |
||||||
 |
 |
|||||||||
BSNatural Brass |
SSStainless Steel |
|||||||||
* May require longer lead time
| Powdercoat Finish Options | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
 |
 |
 |
||||||
WGWhite Gloss |
FWFlat White |
ALAlmond |
BZBronze Metallic |
DGDesert Granite |
||||||
 |
 |
 |
 |
|||||||
WIWeathered Iron |
VFVerde Speckle |
SBSedona Brown |
FBFlat Black |
|||||||
| Step | Description | Code | |||||
|---|---|---|---|---|---|---|---|
| 1 | FIXTURE CODE | LF | |||||
| 2 | OPTIONAL ZD | ZD (zoning and dimming capability using ZD Technology™ with the Luxor controller) | |||||
| 3 | LAMP | 1LED (50,000 avg. life hours) | |||||
| 4 | FINISH | XX (See finish chart) | |||||
EXAMPLE: LF-ZD-1LED-SS = LF – ZD Option – 1LED Board – Stainless Steel Finish
| Number of LEDs | 1 | |
|---|---|---|
| Halogen Lumen Output Equivalent |
10 Watt | |
| Useful LED Life (L70) | 50,000 hrs avg | |
| Input Voltage | 10 to 15V | |
| VA Total (Use this number to size the transformer) |
2.4 | |
| Watts Used | 2.0 | |
| Lumens per Watt (Efficacy) |
37 | |
| Max Lumens | 77 | |
| CRI (Ra) | 81.6 | |
